項(xiàng)目Item | 單位unit | 63T | 100T | 160T | 200T | 315T | 400T | 500T | 630T | 800T | |
公稱力Nominal force | KN | 630 | 1000 | 1600 | 2000 | 3150 | 4000 | 5000 | 6300 | 8000 | |
頂出力Ejecting force | KN | 100 | 200 | 250 | 400 | 630 | 630 | 1000 | 1250 | 1800 | |
液體最大工作壓力Maximum fluid operating pressure | Mpa | 24.3 | 25.8 | 25.5 | 24.4 | 24.6 | 24.7 | 25 | 25 | 24.4 | |
滑塊最大行程Maximum slide stroke | mm | 500 | 500 | 500 | 700 | 800 | 800 | 900 | 900 | 1000 | |
最大開口高度Maximum opening height | mm | 700 | 900 | 900 | 1120 | 1250 | 1400 | 1500 | 1500 | 1800 | |
頂出缸行程Ejecting cylinder stroke | mm | 160 | 200 | 200 | 250 | 300 | 300 | 300 | 400 | 400 | |
| mm/s | 120 | 100 | 100 | 100 | 100 | 100 | 100 | 100 | 100 | |
滑塊速度 | 快下Quick descending |
| 8—15 | 8—15 | 8—15 | 8—15 | 8—15 | 8—15 | 10 | 12 | 5—12 |
Slide speed | 壓制Pressing |
| 600 | 60 | 70 | 70 | 70 | 70 | 80 | 65 | 80 |
工作臺Operating table | 回程Return stroke | mm | 780 | 1800 | 1000 | 1200 | 1500 | 1560 | 4100 | 4390 | 4300 |
有效尺寸Effective size | 左右Left/Right |
| 500 | 1020 | 800 | 900 | 1200 | 1200 | 2420 | 2520 | 2500 |
主電機(jī)功率Main motor power | 前后Forward/Backward | kW | 5.5 | 5.5 | 11 | 12 | 15 | 22 | 37 | 55 | 75 |
